The IP SIP Video Door Phone with + benefits

Our line of door ip phones are designed to achieve
more possible applications with less hardware installation.
FAMILY PRODUCTS
About Us

SURIX

Developing communications technology since 1998.



Surix designs and manufactures IP & analog Door Phone systems for buildings, IP nurse call systems for hospitals, IP access control systems and IP speakers for public announcement.


Surix is expanding its market and offers the opportunity to becoming distributor or reseller directly from the manufacturer. If you are developer, dealer or distributor, you can be part of this team and offer to your customers low cost, smart design and excellent quality products.


We love projects, we offer our engineering know how to help you
to develop the solution your customer needs



See the possibilities of our products.

IP DoorPhone Surix



  Technical Features

  • 2 to 4 configurable push buttons inputs (or sensors)
  • Telephone 3x4 keypad*
  • Mic input
  • Speaker out (low impedance)
  • Line out (high impedance)
  • 1 or 2 Ethernet ports PoE*
  • Vdc or Poe powered*
  • 2 Wiegand interfaces (1 serial TTL interface)*
  • Power on led
  • Status led (software controlled) *
  • 4 external leds outputs for signalling*
  • 2 relays configurable NO/NC*
  • Audio power up to 20 W*
  • Special connector for direct video camera interface
* depends on type of product

Antivandal case (Titanium)

IP doorphone flush mount an surface mount

Standard case

IP doorphone flush mount an surface mount


Feactures and model of standard case

Model Dial Services Power Mounting Picture
IPAX-B-F 1 Button - Video capability w/external camera
- RFID from external device
PoE 802.3af or 12 Vdc Flush IPAX-B-F
IPAX-B-S 1 Button - Video capability w/external camera
- RFID from external device
PoE 802.3af or 12 Vdc Surface IPAX-K-F
IPAX-K-F Keypad - Video capability w/external camera
- RFID from external device
PoE 802.3af or 12 Vdc Flush IPAX-K-F
IPAX-K-S Keypad - Video capability w/external camera
* Proximity Card Reader integrated
PoE 802.3af or 12 Vdc Surface IPAX-K-F
IPAX-BR-F 1 Button - Video capability w/external camera
* Proximity Card Reader integrated
PoE 802.3af or 12 Vdc Flush IPAX-BR-F
IPAX-BR-S 1 Button - Video capability w/external camera
* Proximity Card Reader integrated
PoE 802.3af or 12 Vdc Surface IPAX-BR-S
IPAX-BC-F 1 Button - RFID from external device
* Video camera integrated
PoE 802.3af or 12 Vdc Flush IPAX-BC-F
IPAX-KC-F Keypad - RFID from external device
* Video camera integrated
PoE 802.3af or 12 Vdc Flush IPAX-KC-F


Feactures and model of antivandal case (Titanium)

Model Dial Services Power Mounting Picture
IPTi-B-S 1 Button - Video capability w/external camera
- RFID from external device
PoE 802.3af or 12 Vdc Surface IPTi-B-S
IPTi-BR-S 1 Button - Video capability w/external camera
* Proximity Card Reader integrated
PoE 802.3af or 12 Vdc Surface IPTi-BR-S
IPTi-BC-S 1 Button - RFID from external device
* Video camera integrated
PoE 802.3af or 12 Vdc Surface IPTi-BC-S
IPTi-BCR-S 1 Button * Video camera integrated
* Proximity Card Reader integrated
PoE 802.3af or 12 Vdc Surface IPTi-BCR-S
IPTi-K-S Keypad - Video capability w/external camera
- RFID from external device
PoE 802.3af or 12 Vdc Surface IPTi-K-S
IPTi-KR-S Keypad - Video capability w/external camera
* Proximity Card Reader integrated
PoE 802.3af or 12 Vdc Surface IPTi-KR-S
IPTi-KC-S Keypad * Video camera integrated
- RFID from external device
PoE 802.3af or 12 Vdc Surface IPTi-KC-S
IPTi-KCR-S Keypad * Video camera integrated
* Proximity Card Reader integrated
PoE 802.3af or 12 Vdc Surface IPTi-KCR-S


Certified Interoperability Technology Partners.

Intelligent design

Our products won design awards an ensuring proper installation and product shelf life.

Ready to Ship

Surix exported to over 14 countries with excellent success stories. What do you expect to be successful?

Up to Date

Our products can be reprogrammed to suit all types of projects, also can update software and gain new functionality.

Made with experience

Our products can expand capabilities or combined with existing products on the market, thanks to the guaranteed interoperability. *



Applications.. a world of possibilities

Door Phone for farms
Through a directional WiFi link very low cost, and IP intercom, you can have the door phone service to distance.
Doorphone for pharmacies on duty
Some 24h business can be remotely attended with confort and safety.
Door phone to cell calls
Whoever has a data connection on your mobile phone, you can play your home doorphone in his cell, either to keep visitors called (mail, messenger, etc.) or to simulate presence.
SOS post for highways
Emergency situations can be solved with high performance IP call (high volume), through digital connections. The IP protocols allow study not only voice communication but also information on the state of the post.
Panic button
The IP vandal housing, doorphone allow to have alerting means by which citizens can warn the authorities, through the monitoring center operators.
Evacuation and pager
Today, thanks to IP speakers, you can directly install the speaker, to the data network of the company, registered to the same central telephone company as an extension.
Ads in supermarkets and shopping malls
The IP speakers allow this function to be controlled locally in each branch, but also to send messages from a headquarters to announce simultaneous offers in all branches.
Concierge and intercom system for old buildings
The multi-line system an ideal solution in buildings where installing ip doorphone did not foresee or there is an intercom system no longer fulfills its function correctly.
Information booths
A place with IP intercom is an ideal and inexpensive solution as it can be distributed in different places, helping people to make inquiries.
